- Title
- VIS-NIR reflectance spectra of binary mixtures of silicon dioxide (SiO2) particles (0.5 - 10 µm) and Juniper charcoal particles (less than 50 µm)
- DOI
- 10.26302/SSHADE/EXPERIMENT_CF_20200813_000
- Data reference
- Feller, Clement (2020): VIS-NIR reflectance spectra of binary mixtures of silicon dioxide (SiO2) particles (0.5 - 10 µm) and Juniper charcoal particles (less than 50 µm). SSHADE/BYPASS (OSUG Data Center). Dataset/Spectral Data. https://doi.org/10.26302/SSHADE/EXPERIMENT_CF_20200813_000
- Publications
- Database(s)
- Experimentalists
- Type(s)
- laboratory measurement
- Number of spectra
- 11
- Variable type(s)
-
- sample composition
- Instrument
- MoHIS - Hyperspectral imaging system Vis-NIR
- Standard medium
- vacuum
- Observation mode
- spectrum
- Spectral range type(s)
- Vis, NIR
- Valid spectral range(s)
-
Min - Max ($nm$) Sampling ($nm$) Resolution ($nm$) Position accuracy ($nm$) Absorption edge #1 400.0 - 940.0 15.0 6.5 #2 946.0 - 1294.0 6.0 6.5 #3 1300.0 - 2404.0 6.0 13.0
Definition: incidence and emergence angles are positive with origin at nadir, and vary in same direction. Azimuth origin (increasing clockwise) is for i = e (opposition geometry).
- Observation geometry
- biconical
- Observation mode
- fixed angles
- Incidence angle
- 5.0°
- Emergence angle
- 0.0°
- Azimuth angle
- 0.0°
- Phase angle
- 5.0°
- Observation mode
- roi averaged
- Spots number
- 4
- Date begin - end
- 2020-08-13 - 2020-08-14
Versions
- Release date
- 2023-12-07 08:37:16 UTC+0000
- Version (Date)
- #1 (2023-12-07 08:37:16 UTC+0000, Updated: 2023-12-07 08:37:16 UTC+0000)
- Sponsors
-
- Swiss National Science Fundation (SNSF)
- Comets Physics Laboratory (CoPhyLab)
