- DOI
- 10.26302/SSHADE/EXPERIMENT_LB_20200226_001
- Data reference
- Quirico, Eric; Montagnac, Gilles (2006): UV Raman spectra (λ = 244 nm) of chondritic IOM (CI, CM, CR, ung.). SSHADE/GhoSST (OSUG Data Center). Dataset/Spectral Data. https://doi.org/10.26302/SSHADE/EXPERIMENT_LB_20200226_001
- Publications
- Database(s)
- Experimentalists
- Type(s)
- laboratory measurement
- Number of spectra
- 14
- Variable type(s)
-
- sample composition
- spectrum type
- Instrument
- labRAM HR800 micro-Raman UV - 244nm
- Sample holder
- microscope glass slide in ambient room air
- Standard medium
- air
- Observation mode
- spectrum
- Spectral range type(s)
- MIR
- Valid spectral range(s)
-
Min - Max ($cm^{-1}$) Sampling ($cm^{-1}$) Resolution ($cm^{-1}$) Position accuracy ($cm^{-1}$) Absorption edge #1 400.0 - 4000.0 - Filters
-
Type Center/Edge ($cm^{-1}$) Width ($cm^{-1}$) Place #1 notch filter 0.0 - Comments
- Notch filter: (514 +/- x) nm + neutral density filter
- Observation geometry
- other geometry
- Observation mode
- fixed angles
- Observation mode
- single spot
- Objective type
- x40
- Pixels number
- 1 x 1
- Image size
- 4.0 x 4.0 ${\mu}m$
- Date begin
- 2006-01-01
Versions
- Release date
- 2020-06-02 14:50:18 UTC+0000
- Version (Date)
- #1 (2020-06-02 14:50:18 UTC+0000, Updated: 2020-06-02 14:50:18 UTC+0000)
