Co K edge XAS transmission of Co oxides at 300K | FAME

Experiment

Title: Co K edge XAS transmission of Co oxides at 300K

References

DOI: 10.26302/SSHADE/EXPERIMENT_PS_20101901_004
Data reference: Strobel, Pierre; Darié, Céline; Proux, Olivier (2010): Co K edge XAS transmission of Co oxides at 300K. SSHADE/FAME (OSUG Data Center). Dataset/Spectral Data. https://doi.org/10.26302/SSHADE/EXPERIMENT_PS_20101901_004

Owner

Database(s)

FAME

Experimentalists

Spectra preview

Experiment type

Type(s): laboratory measurement
Number of spectra: 3
Comments: These data were acquired on the BM30 beamline in the frame of the 30-02-995 proposal.

Variable parameters

Variable type(s)

sample composition

Location

Laboratory: French Absorption spectroscopy beamline in Material and Environmental science (FAME)

Instrument #1

Instrument: X-ray Absorption Spectroscopy measured in transmission mode
Sample holder: simple holder

Spectral parameters

Standard medium

unknown

Observation mode

spectrum

Spectral range type(s)

hard X

Valid spectral range(s)

	Min - Max ( $eV$ )	Sampling ( $eV$ )	Resolution ( $eV$ )	Position accuracy ( $eV$ )	Absorption edge
#1	7580.0 - 8350.0		0.395		$Co$ (K: 7.7089 $keV$ )

Comments

The resolution in the above table is the resolution given by the monochromator. The energy was calibrated by measuring the absorption edge of a reference: Co metallic foil (first maximum of the derivative set at 7709 eV).

Angular parameters

Definition: incidence and emergence angles are positive with origin at nadir. Emergence angle in transmission is larger than 90° (=180°-i).

Observation geometry: direct
Observation mode: fixed angles

Spatial parameters

Observation mode: averaged

History

Date begin - end: 2010-01-19 - 2010-01-24

Versions

Release date: 2025-03-26 08:46:12 UTC+0000
Version (Date): #1 (2025-03-26 08:46:12 UTC+0000, Updated: 2025-03-26 08:46:12 UTC+0000)
