Sample
Name
Pyrrhotite sub-micrometer size grains in a sublimate residue at 173 K
Database
Experimentalists
Date
2018-07-21
Sublimate residue of pure pyrrhotite sub-micrometer size grains at 173 K inside the sample holder (48 mm in diameter and 5 mm deep) in the CARBONIR simulation chamber.
Fragments of the sublimate residue of pure pyrrhotite grains measured by Scanning Electron Microscopy outside the simulation chamber on 05/10/2018. The pyrrhotite grains are arranged in fluffy aggregates.
Zoom on a fragment of the sublimate residue of pure pyrrhotite grains measured by Scanning Electron Microscopy outside the simulation chamber on 05/10/2018. The pyrrhotite grains are sub-micrometric to micrometric in size and some have platelet-like shapes.
Zoom on a fragment of the sublimate residue of pure pyrrhotite grains measured by Scanning Electron Microscopy outside the simulation chamber on 05/10/2018. The pyrrhotite grains are sub-micrometric to micrometric in size and some have platelet-like shapes.
Physical characteristics
Thickness
1.0 $\pm$ 0.5 $mm$
Diameter
48.0 $mm$
Substrate material
aluminum sample holder
Substrate comments
The sample holder is 48 mm in diameter and 5 mm deep
Temperature
173.0 $K$
Temperature max
173.0 $K$
Type
vacuum
Comments
Primary vacuum, less than 10^-5 mbar
Publications
Number
1
Layers
