Nontronite NAu-1 with 0-36 µm grain size | CSS | SSHADE

Sample

Name: Nontronite NAu-1 with 0-36 µm grain size

Owner of sample

Database

CSS

Experimentalists

Origin of sample

Date: 2018-06-15
Provider: Marco Ferrari and Simone De Angelis, Istituto di Astrofisica e Planetologia Spaziali-INAF, Rome, Italy

Sample of nontronite NAu-1 with 0-36 µm grain size, in the 5-mm thick sample holder as it was measured.

Nontronite NAu-1 with 0-36 µm grain size, observed with a Scanning Electron Microscope (SEM).

Physical characteristics

Thickness: 5.0 $\pm$ 1.0 $mm$
Substrate material: aluminum
Substrate comments: raw aluminum sample holder cylindrical 5 mm deep.

Sample environment: Temperature

Temperature: 299.0 $\pm$ 2.0 $K$

Sample environment: Fluid

Type: vacuum
Fluid temperature: 299.0 $K$
Fluid pressure: 1.5e-05 $mbar$

Layers in sample

Number

1

Layers

Nontronite NAu-1 with 0-36 µm grain size , 5.0 $mm$
